        64MP Sony IMX686 MIPI Interface Auto Focus Camera Module
        Model No.   KLT-5067-IMX686 V3.0








 Camera Module No. KLT-5067-IMX686 V3.0
 Resolution 64MP
 Image Sensor IMX686
 Sensor Type 1/1.73"
 Pixel Size 0.8 um x 0.8 um
 EFL 5.43 mm
 F.NO 1.89
 Pixel 9284 x 6944
 View Angle 79.8° (DFOV)
 Lens Dimensions 11.80 x 11.30 x 6.62 mm
 Module Size 19.30 x 11.80 mm
 Module Type Auto Focus
 Interface MIPI C-PHY
 Auto Focus VCM Driver IC DW9800W
 Lens Type 650nm IR Cut
 Operating Temperature -20°C to +85°C
 Mating Connector BM20B(0.8)-30DS-0.4V(51)
