5MP Sony IMX335 M12 Fixed Focus USB 3.0 Camera Module
|
| Model No. KLT-UFA90-IMX335 V1.0 |
| Camera Module No. |
KLT-UFA90-IMX335 V1.0 |
| Resolution |
5MP |
| Image Sensor |
IMX335 |
| Sensor Type |
1/2.8" |
| Pixel Size |
2.0 um x 2.0 um |
| EFL |
8.04 mm |
| F.NO |
4.00 |
| Pixel |
2592 x 1944 |
| View Angle |
50.2°(DFOV) 43.4°(HFOV) 24.0°(VFOV) |
| Lens Dimensions |
13.65 x 13.65 x 23.27 mm |
| Module Type |
Fixed Focus |
| Interface |
USB 3.0 |
| Output Format |
MJPG / YUV2 |
| Auto Control |
Saturation, Contrast, Acutance
White Balance, Exposure |
| Audio |
None |
| Input Voltage |
DC 5V |
| Working Current |
Max 500mA |
| PCB Size |
32mm x 32mm |
| System Compatibility |
Windows XP (SP2, SP3), Vista, 7, 8, 10, 11
Android, Mac OS, Linux or OS with UVC Driver
Raspberry Pi by USB Port |
| Software for USB Camera |
AMCAP, Webcam Viewer, V4L2 Controls
Contacam, VLC Player, MotionEye OS
iSpy, ZoneMider, Yawcam |
| Lens Type |
650nm IR Cut |
| Operating Temperature |
-30°C to +85°C |
| USB Cable |
USB Cable |
|
